Detecting Building Façade Damage Caused by Earthquake Using CBAM-Improved Mask R-CNN
-
摘要: 震后建筑物损毁信息是灾情快速评估和应急救援的重要决策依据之一。针对传统的建筑物损毁遥感检测技术只关注于顶面信息，导致众多顶面结构完好而中间层、底层倒塌或崩裂的损毁建筑物处于检测盲点的问题，提出了一种融合引入注意力机制的深度学习实例分割模型和图像多尺度分割算法进行震后建筑物立面损毁检测的方法。首先，利用卷积块状注意力模块（convolutional block attention module, CBAM）改进掩模区域卷积神经网络（mask region-based convolutional networks, Mask R-CNN)模型实现了复杂建筑物立面背景中的损毁信息提取；然后，基于建筑物立面影像多尺度分割结果，利用多数投票规则实现了损毁检测结果的后处理优化。实验结果表明，相比传统损毁检测方法，所提方法能够更有效地实现震后建筑物立面损毁信息的精准定位，总体准确率可达到89.15%。Abstract:Objectives Building damage information can provide an important basis for the decision making of rapid post-earthquake assessment. Traditional building damage detection techniques mainly focus on the roof surface, thus many damaged buildings with an intact roof surface but collapsed middle floors may be neglected. We propose a method of building façade damage detection based on deep learning and multiresolution segmentation algorithm.Methods The method which integrates the instance segmentation and multiresolution segmentation algorithm is applied to detecting the post-earthquake building façade damage. The first thing is to collect the ground images of post-earthquake buildings in the field and perform the data augmentation. Secondly, we use the convolutional block attention module (CBAM) to improve Mask R-CNN. Then the dataset is input to the improved model for training, and finally a multiresolution segmentation algorithm is adopted to post-process the building façade damage detection results output by the CBAM-Improved Mask R-CNN.Results The experimental results show: (1) Collecting ground images of buildings in the field and performing image augmentation can effectively guarantee the necessary training sample size of the instance segmentation model. (2) The Mask R-CNN improved by CBAM attention mechanism significantly improves the post-earthquake building facade damage detection capabilities, which realizes the precise extraction of damage information from complex building façade backgrounds. (3) In addition, using the multiresolution segmentation algorithm to post-process the building facade damage detection results can obviously solve the blurred boundary problems caused by the accumulation of convolutional layers.Conclusions The proposed method can significantly improve the capability of post-earthquake building façade damage detection when compared to the traditional methods, which also raises the Mask R-CNN's accuracy, precision, recall and F2-score to a certain degree. It can be inferred that the proposed method has the strong potential to be applied to the post-earthquake building façade damage detection and therefore provides an important technical means for detecting the comprehensive and detailed building damage detection caused by earthquake.
-
-
![]()
图 1 震后顶面完好而立面破损的建筑物
Figure 1. Post-Earthquake Building with an Intact Roof Surface and Damaged Façade
![]()
图 2 震后建筑物立面损毁检测流程图
Figure 2. Flowchart of Post-Earthquake Building Facade Damage Detection
![]()
图 5 引入CBAM注意力机制的Mask R-CNN模型特征提取网络
Figure 5. Feature Extraction Network of Mask R-CNN Model Improved by CBAM Attention Mechanism
![]()
图 8 CMR模型输出北川遗址建筑物立面损毁检测结果
Figure 8. Beichuan Building Façade Damage Detection Results Using CMR Model
![]()
图 9 CMR模型输出汉旺遗址建筑物立面损毁检测结果
Figure 9. Hanwang Building Façade Damage Detection Results Using CMR Model
表 1 精度比较/%
Table 1 Comparison of the Performance/%
模型 准确率 精确率 召回率 F2分数 BOVW 67.78 32.55 40.19 33.74 Mask R-CNN 86.91 65.91 61.72 62.70 本文方法 89.15 72.19 68.01 68.20
下载: 导出CSV
-
[1] 李强, 张景发.不同特征融合的震后损毁建筑物识别研究[J].地震研究, 2016, 39(3):486-493 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzyj201603018 Li Qiang, Zhang Jingfa. Research on Earthquake Damaged Building Extraction by Different Features Fusion[J].Journal of Seismological Research, 2016, 39(3):486-493 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzyj201603018
[2] 陶和平, 刘斌涛, 刘淑珍, 等.遥感在重大自然灾害监测中的应用前景:以5·12汶川地震为例[J].山地学报, 2008, 26(3):276-279 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sdxb200803005 Tao Heping, Liu Bintao, Liu Shuzhen, et al. Natural Hazards Monitoring Using Remote Sensing: A Case Study of 5-12 Wenchuan Earthquake[J]. Journal of Mountain Science, 2008, 26(3):276-279 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sdxb200803005
[3] 眭海刚, 刘超贤, 黄立洪, 等.遥感技术在震后建筑物损毁检测中的应用[J].武汉大学学报·信息科学版, 2019, 44(7):1 008-1 019 doi: 10.13203/j.whugis20190070 Sui Haigang, Liu Chaoxian, Huang Lihong, et al. Application of Remote Sensing Technology in Earthquake-Induced Building Damage Detection[J]. Geomatics and Information Science of Wuhan University, ,2019, 44(7):1 008-1 019 doi: 10.13203/j.whugis20190070
[4] 贾宁, 赵鹏祥.浅谈众源地理数据[J].中国科技信息, 2013(12):42 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgkjxx201312007 Jia Ning, Zhao Pengxiang. Crowdsourcing Geographic Data[J]. China Science and Technology Information, 2013 (12):42 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgkjxx201312007
[5] 姜青香, 刘慧平.利用纹理分析方法提取TM图像信息[J].遥感学报, 2004, 8(5):458-464 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ygxb200405012 Jiang Qingxiang, Liu Huiping.Extracting TM Image Information Using Texture Analysis[J]. Journal of Remote Sensing, 2004, 8(5):458-464 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ygxb200405012
[6] 涂继辉, 眭海刚, 吕枘蓬, 等.基于基尼系数的倾斜航空影像中建筑物立面损毁检测[J].武汉大学学报-信息科学版, 2017, 42(12):1 744-1 748 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=whchkjdxxb201712010 Tu Jihui, Sui Haigang, Lv Ruipeng, et al. Building Facade Damage Detection Based on the Gini Index from Oblique Aerial Images[J]. Geomatics and Information Science of Wuhan University, 2017, 42(12):1 744-1 748 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=whchkjdxxb201712010
[7] Vetrivel A, Gerke M, Kerle N, et al. Identification of Structurally Damaged Areas in Airborne Oblique Images Using a Visual-Bag-of-Words Approach[J]. Remote Sensing, 2016, 8(3): 231-252 doi: 10.3390/rs8030231
[8] Kerle N, Fernandez G J, Gerke M.Urban Structural Damage Assessment with Oblique UAV Imagery, Object-Based Image Analysis and Semantic Reasoning[C].The 35th Asian Conference on Remote Sensing, Nay Pyi Taw, Myanmar, 2014
[9] Fernandez G J, Kerle N, Gerke M. UAV-Based Urban Structural Damage Assessment Using Object-Based Image Analysis and Semantic Reasoning[J]. Natural Hazards & Earth System Sciences, 2015, 15(6):1 087-1 101 http://www.tandfonline.com/servlet/linkout?suffix=CIT0014&dbid=16&doi=10.1080%2F10447318.2018.1427831&key=10.5194%2Fnhess-15-1087-2015
[10] He K, Gkioxari G, Dollár P, et al. Mask R-CNN[C]. The IEEE International Conference on Computer Vision, Venice, Italy, 2017
[11] Ren S, He K, Girshick R, et al. Faster R-CNN: Towards Real-Time Object Detection with Region Proposal Networks[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(6):1 137-1 149 doi: 10.1109/TPAMI.2016.2577031
[12] Long J, Shelhamer E, Darrell T. Fully Convolutional Networks for Semantic Segmentation[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2015, 39(4): 640-651 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=994776c264e86f91bd6bda7f694c7564
[13] Woo S, Park J, Lee J Y, et al. CBAM: Convolutional Block Attention Module[C]. The European Conference on Computer Vision, Munich, Germany, 2018
[14] He K, Zhang X, Ren S, et al. Deep Residual Learning for Image Recognition[C].IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Las Vegas, USA, 2016
[15] 谢飞, 穆昱, 管子玉, 等.基于具有空间注意力机制的Mask R-CNN的口腔白斑分割[J].西北大学学报(自然科学版), 2020, 50(1): 9-15 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdxxb202001002 Xie Fei, Mu Yu, Guan Ziyu, et al.Oral Leukoplakia (OLK) Segmentation Based on Mask R-CNN with Spatial Attention Mechanism[J].Journal of Northwest University(Natural Science Edition), 2020, 50(1):9-15 http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdxxb202001002
-
